Square D HJA36080 3 Pole Circuit Breaker
$500.00
Skip to product information
5 left
Square D HJA36080 3 Pole Circuit Breaker
$500.00
Shipping calculated at checkout.
Pickup available at 2201 Midway Rd ste 314
Usually ready in 2 hours
The Square D HJA36080 is a 3-pole, 80 Amp high-interrupting circuit breaker specifically designed for use in I-Line panelboards. The "J" rating is the standout feature here, providing a massive 65kA of interrupting capacity at 480V, which is nearly four times the protection of the standard "D" rated model. It features a thermal-magnetic trip element that provides both reliable long-time overcurrent protection and instantaneous high-fault protection. This breaker is typically used in industrial facilities, hospitals, or data centers where the electrical system is close to a high-capacity power source and requires superior fault withstand capabilities.
Specifications:
|
Brand |
Square D (Schneider Electric) |
|---|---|
|
Series |
PowerPact H-Frame (I-Line) |
|
Amperage |
80 |
|
Voltage |
600V AC / 250V DC |
|
Poles |
3 |
|
Phase |
3 |
|
Interrupting Rating |
100kAIC at 240V / 65kAIC at 480V / 25kAIC at 600V |
|
Frame Type |
H-Frame (J-Interrupting Level) |
|
Protection Type |
Thermal Magnetic |
|
Terminal |
I-Line (Line Side) / Mechanical Lugs (Load side) |
|
Mpn |
HJA36080 |
|
Upc |
785901547051 |
