Square D FAL24020 2 Pole Circuit Breaker
$125.00
Skip to product information
5 left
Square D FAL24020 2 Pole Circuit Breaker
$125.00
Shipping calculated at checkout.
Pickup available at 2201 Midway Rd ste 314
Usually ready in 2 hours
The Square D FAL24020 is a 2-pole, 20 Amp molded case circuit breaker designed for heavy-duty industrial and commercial applications. As part of the F-Frame family, it provides versatile protection for branch circuits and small motor loads. It is unique for its high voltage ceiling, rated up to 480V AC, despite its low amperage. This unit is built in a compact frame that allows for easy integration into control panels or legacy distribution systems. It comes standard with mechanical lugs on both the line and load ends, making it a "standalone" breaker that does not require a specific panelboard bus connection.
Specifications:
|
Brand |
Square D |
|---|---|
|
Series |
F-Frame (Legacy) |
|
Amperage |
20 |
|
Voltage |
480V AC / 250V DC |
|
Poles |
2 |
|
Phase |
1 |
|
Interrupting Rating |
25kAIC at 240V, 18kAIC at 480V |
|
Frame Type |
F-Frame (Unit Mount) |
|
Protection |
Thermal Magnetic |
|
Terminal |
Mechanical Lugs (Both line and Load sides) |
|
Mpn |
FAL24020 |
|
Upc |
785901438129 |
