Square D EDB14020 1 Pole Circuit Breaker
$25.00
Skip to product information
In stock
Square D EDB14020 1 Pole Circuit Breaker
$25.00
Shipping calculated at checkout.
Pickup available at 2201 Midway Rd ste 314
Usually ready in 2 hours
The Square D EDB14020 is a 20 Amp, single-pole Bolt-On circuit breaker from the E-Frame family, designed for Square D NF panelboards. This thermal-magnetic breaker provides reliable overcurrent protection for 480Y/277V AC commercial and industrial applications. Its bolt-on design ensures a secure, vibration-resistant connection to the bus bar, making it ideal for permanent installations in demanding environments.
Specifications
| Brand | Square D (Schneider Electric) |
| Series | E-Frame (Bolt-on) |
| Amperage | 20 |
| Voltage | 480Y/277V AC |
| Poles | 1 |
| Phase | 1 |
| Interrupting Rating | 18 kAIC at 277V AC |
| Frame Type | EDB |
| Protection | Thermal-Magnetic |
| Terminal | Bolt-on (Line side) / Box Lug (Load side) |
| Wire Size | AWG #14 to #6 (Copper/Aluminum) |
| MPN | EDB14020 |
| UPC | 785901874620 |
